STANDARD AUTO CRUISER SPECIFICATION:
• Spare wheel on a bracket
• LED lights
• Supporting loading legs
• Set of loading ramps
• 80mm wide rails down the side of chassis with strapping points every 300mm
• Storage box 700mm long x 182mm wide x 235mm height
• 50mm ball coupling with barrel lock and safety ball
2100mm (6’11”) can be changed to 2220mm and 2400mm (7’3″ and 8′).2230mm (7’3″) can be changed to 2100 and 2400mm (6’11 and 8′).
Full Specification
| Model | Bed Dimensions (B, A) | Load (kg) | Gross (kg) | Empty Trailer Weight (kg) | Axles | Wheel Size (inches) | O/A Width (C) (mm) | O/A Length (D) (mm) | Loading Angle (degrees) | Bed Height (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| AC142600 | 14′ x 6’11” (4290 x 2120) | 1918 | 2600 | 682 | 2 | 12//10 | 2120 | 5790 | 12 | 620/600 |
| AC143000 | 14′ x 6’11” (4290 x 2120) | 2305 | 3000 | 695 | 2 | 12//10 | 2120 | 5790 | 12 | 620/600 |
| AC162600 | 16′ x 6’11” (4900 x 2120) | 1878 | 2600 | 722 | 2 | 12//10 | 2120 | 6400 | 12 | 620/600 |
| AC163000 | 16′ x 6’11” (4990 x 2120) | 2265 | 3000 | 735 | 2 | 12//10 | 2120 | 6400 | 12 | 620/600 |
| AC163500 | 16′ x 6’11” (4990 x 2120) | 2721 | 3500 | 779 | 2 | 12 | 2120 | 6400 | 12 | 600 |
| AC1835003 | 18′ x 7’3″ (5500 x 2220) | 2650 | 3500 | 850 | 3 | 10 | 2220 | 6900 | 11 | 620/600 |
| AC2035003 | 20′ x 7’3″ (6100 x 2220) | 2550 | 3500 | 950 | 3 | 10 | 2220 | 7500 | 11 | 600 |
| ACLT162600 | 16′ x 6’11” (4900 x 2120) | 2018 | 2600 | 582 | 2 | 12//10 | 2120 | 6400 | 12 | 620/600 |
| ACLT163000 | 16′ x 6’11” (4900 x 2120) | 2408 | 3000 | 592 | 2 | 12//10 | 2120 | 6400 | 12 | 620/600 |
All our Auto Cruiser trailers come as standard with a spare wheel (12kg included), LED Lights, punched 500mm wide deck runners full length or full width floor (56kg), rails 80mm wide each side of chassis with strapping points every 300mm, set of loading ramps 2.4m long (60kg pair), storage box 700mm long x 182mm wide x 235mm height (9.2kg), 50mm ball coupling with barrel lock and safety ball and supporting loading legs.
Optional Extras
| Extras | Product |
| 120VA12F | Warrior Samurai Next Gen 12000 Winch 12v Synthetic |
| 120VS12F | Samurai Next Gen 12000 Winch 12v Steel Rope |
| 25SPS12F | WARRIOR NINJA 2500 winch 12V Steel rope |
| 35SPA12F | Warrior Ninja 3500 winch synthetic rope |
| 35SPS12F | WARRIOR NINJA 3500 winch 12V Steel rope |
| 45SPA12F | Warrior Ninja 4500 winch 12v Synthetic rope |
| 45SPS12F | WARRIOR NINJA 4500 WINCH 12v Steel rope |
| 950VA12F | Warrior Samurai Next Gen 9500 winch 12v Synthetic |
| 950VS12F | Warrior Samurai next gen 9500 winch 12v Steel rope |
| 95DVA12F | Samurai Next Gen 9500 Short Drum Winch 12V Steel |
| OP002 | Centre deck storage (underfloor storage) |
| OP006 | 2 JERRY CAN HOLDER/FUEL BOX |
| OP007 | 3 JERRY CAN HOLDER/ FUEL BOX(Not available for tilt beds ) |
| OP009 | STRAP BOX 9 WEIGHT 9.2 KG |
| OP014 | SET OF 4 MEDIUM DUTY STRAPS WITH LOOPS |
| OP015 | SET OF 4 HEAVY DUTY STRAPS WITH LOOPS |
| OP015/1 | SET OF 4 HEAVY DUTY STRAPS (OVERWHEEL) |
| OP019 | MANUAL 2 SPEED WINCH 2500LB |
| OP020 | MANUAL SINGLE SPEED WINCH 3200LB |
| OP021 | MANUAL SINGLE SPEED WINCH 3500LB |
| OP023 | Crossover ramps |
| OP031 | WIRELESS REMOTE CONTROL FOR ELECTRIC WINCH |
| OP050 | Headboard |
| OPMPO1 | MANUAL HYDRAULIC TILT |
| WK11512SF | 11500LB EL WINCH WITH SYNTETIC ROPE |
| WK11512WF | 11500LB WINCH 51kN 12V WINCH STEEL WIRE |
| WK13512WF | 13500 LBSC 12V WINCH STEEL WIRE |
| WK45012SBF | 4500LB 12V WINCH SYNTETIC ROPE |
| WK45012WBF | 4500LB WINCH STEEL WIRE WITH WIRED CONTROLLER |
| WK95012SF | 9500LB SYNTHETIC ROPE 42.3KN 12V |
| WK95012WF | 9500LBS 42.3KN 12V WINCH STEEL WIRE |
| WTRTG220 | 7’3″ (2220MM) RAMP TAILGATE ( UPGRADE) |
| WTSWC | Spare wheel soft cover |
| WTWC | ADJUSTABLE FULL WIDTH WHEEL STOP WITH TWO RAILS |
| WTWSC | Soft winch cover for electric winch |
