Full Specification
| Model No. | Bed Width (mm) | Load (kg) | Gross (kg) | Gap Between Runways (kg) | Axles (number) | O/A Length (mm) | O/A Width (mm) | Bed Length (mm) | Wheel Size (inches) | Ramp Length / Width (mm) | Mudguard Height from Ground (mm) | Height from Runway to Top of Mudguard (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MBT010 | 1400 | 550 | 750 | 200 | 1 | 3200 | 1900 | 2400 | 10’’ 145 / 10’’4 STUD 100 PCD | 1200 / 170 | 520 | 215 |
Optional Extras
| Part Number | 3 Bike Trailer Optional Extras | Weight | Clamp distance |
| MBTCS | 1 Set of clamps | 7kg per set | 300mm |
