STANDARD LIGHTWEIGHT SPECIFICATION:
• Spare wheel on bracket
• 50mm ball coupling with barrel lock and safety ball
• Supporting loading drop down legs
• Set of two ramps and medium to heavy duty jockey wheel
Full Specification
| Model No. | Bed Dimensions (ft/in) | Bed Dimensions (mm) | Load (KG) | Gross KG | Empty Trailer Weight (KG) | Axles | Wheel Size (inches) | O/A Width (mm) | O/A Length (mm) | Loading Angle | Gap Between Runways (mm) | Height From Bed to Top of Mudguard | Ramp Length (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LWT010 | 8’x5’5” | 2440 x 1650 | 980 | 1300 | 320 | 1 | 12 | 2120 | 3650 | 8 | 875 | 230 | 1520 |
| LWT011 | 8’x5’7” | 2440 x 1700 | 980 | 1300 | 320 | 1 | 12 | 2170 | 3700 | 8 | 930 | 230 | 1520 |
| LWT020 | 8’8″x5’5″ | 2640 x 1650 | 980 | 1300 | 320 | 1 | 12 | 2120 | 3850 | 8 | 875 | 230 | 1520 |
| LWT021 | 8’8”x5’7” | 2640 x 1700 | 980 | 1300 | 320 | 1 | 12 | 2170 | 3700 | 8 | 930 | 230 | 1520 |
| LWT030 | 10’x5’5″ | 3050 x 1650 | 970 | 1300 | 330 | 1 | 12 | 2120 | 4245 | 8 | 875 | 230 | 1920 |
| LWT031 | 10’x5’7” | 3050 x 1700 | 960 | 1300 | 340 | 1 | 12 | 2170 | 4295 | 8 | 930 | 230 | 1920 |
| LWT032 | 10’x6’1” | 3050 x 1850 | 960 | 1300 | 340 | 1 | 12 | 2300 | 4345 | 8 | 1070 | 230 | 1920 |
| LWT040 | 11’x5’5″ | 3350 x 1650 | 950 | 1300 | 350 | 1 | 12 | 2120 | 4625 | 8 | 875 | 230 | 1920 |
| LWT041 | 11’x5’7” | 3350 x 1700 | 950 | 1300 | 350 | 1 | 12 | 2170 | 4670 | 8 | 930 | 230 | 1920 |
| LWT042 | 11’x6’1” | 3350 x 1850 | 950 | 1300 | 350 | 1 | 12 | 2300 | 4670 | 8 | 1020 | 230 | 1920 |
| LWT050 | 11’x5’5” | 3550 x 1650 | 1200 | 1600 | 400 | 2 | 10 | 2120 | 4670 | 8 | 870 | 210 | 1920 |
| LWT051 | 11’x5’7” | 3350 x 1700 | 1200 | 1600 | 400 | 2 | 10 | 2170 | 4670 | 8 | 930 | 210 | 1920 |
| LWT052 | 11’x6’1” | 3350 x 1850 | 1200 | 1600 | 400 | 2 | 10 | 2300 | 4725 | 8 | 1070 | 210 | 1920 |
| LWT060 | 12’x5’5” | 3660 x 1650 | 930 | 1300 | 370 | 1 | 12 | 2120 | 4925 | 8 | 875 | 230 | 1920 |
| LWT061 | 12’x5’7” | 3660 x 1700 | 940 | 1300 | 360 | 1 | 12 | 2170 | 4970 | 8 | 930 | 230 | 1920 |
| LWT062 | 12’x6’1 | 3660 x 1850 | 940 | 1300 | 360 | 1 | 12 | 2300 | 5025 | 8 | 1070 | 230 | 1920 |
| LWT070 | 12’x5’5” | 3660 x 1650 | 1200 | 1600 | 400 | 2 | 10 | 2120 | 4925 | 8 | 875 | 210 | 1920 |
| LWT071 | 12’x5’7” | 3660 x 1700 | 1200 | 1600 | 400 | 2 | 10 | 2170 | 4970 | 8 | 930 | 210 | 1920 |
| LWT072 | 12’x6’1” | 3660 x 1850 | 1200 | 1600 | 400 | 2 | 10 | 2300 | 5025 | 8 | 1070 | 210 | 1920 |
| LWT073 | 12’x6’1” | 3660 x 1850 | 1500 | 2000 | 500 | 2 | 12/10 | 2300 | 5025 | 8 | 875 | 230 | 1920 |
| LWT080 | 13’x5’5” | 3960 x 1650 | 930 | 1300 | 370 | 1 | 12 | 2120 | 5215 | 8 | 875 | 230 | 1920 |
| LWT081 | 13’x5’7” | 3960 x 1700 | 930 | 1300 | 370 | 1 | 12 | 2170 | 5260 | 8 | 930 | 230 | 1920 |
| LWT082 | 13’x6’1” | 3960 x 1850 | 950 | 1300 | 350 | 1 | 12 | 2300 | 5315 | 8 | 1070 | 230 | 1920 |
| LWT090 | 13’x5’5” | 3960 x 1650 | 1200 | 1600 | 400 | 2 | 10 | 2120 | 5215 | 8 | 875 | 210 | 1920 |
| LWT091 | 13’x5’7” | 3960 x 1700 | 1200 | 1600 | 400 | 2 | 10 | 2170 | 5260 | 8 | 930 | 210 | 1920 |
| LWT092 | 13’x6’1” | 3960 x 1850 | 1200 | 1600 | 400 | 2 | 10 | 2300 | 5315 | 8 | 1070 | 210 | 1920 |
| LWT093 | 13’x6’1” | 3960 x 1850 | 1500 | 2000 | 500 | 2 | 12 | 2300 | 5315 | 8 | 1070 | 210 | 1920 |
| LWT100 | 14’x5’5” | 4270 x 1650 | 1200 | 1600 | 400 | 2 | 10 | 2120 | 5574 | 8 | 875 | 210 | 1920 |
| LWT101 | 14’x5’7” | 4270 x 1700 | 1200 | 1600 | 400 | 2 | 10 | 2170 | 5619 | 8 | 930 | 210 | 1920 |
| LWT102 | 14’x6’1” | 4270×1850 | 1200 | 1600 | 400 | 2 | 10 | 2300 | 5674 | 8 | 1070 | 210 | 1920 |
| LWT103 | 14’x6’1” | 4270×1850 | 1500 | 2000 | 500 | 2 | 12 | 2300 | 5674 | 8 | 1070 | 210 | 1920 |
All of our lightweight trailers come as standard with a spare wheel, hitch lock and supporting drop down legs. They are available in single or twin brake axle options, seven variant bed lengths and four variant bed widths. With a strong, durable lightweight chassis, low bed height and a range topping 1500kg gross capacity our lightweight trailers are perfect to suit your needs.
Optional Extras
| Extras | Product |
| OP001 | Centre deck kit (18mm Buffalo board) |
| OP006 | 2 JERRY CAN HOLDER/FUEL BOX |
| OP007 | 3 JERRY CAN HOLDER/ FUEL BOX(Not available for tilt beds ) |
| OP009 | STRAP BOX 9 WEIGHT 9.2 KG |
| OP014 | SET OF 4 MEDIUM DUTY STRAPS WITH LOOPS |
| OP014/1 | SET OF 4 MEDIUM DUTY STRAPS |
| OP015 | SET OF 4 HEAVY DUTY STRAPS WITH LOOPS |
| OP015/1 | SET OF 4 HEAVY DUTY STRAPS (OVERWHEEL) |
| OP017 | Pair of two wheel stops |
| OP019 | MANUAL 2 SPEED WINCH 2500LB |
| OP020 | MANUAL SINGLE SPEED WINCH 3200LB |
| OP021 | MANUAL SINGLE SPEED WINCH 3500LB |
| OP031 | WIRELESS REMOTE CONTROL FOR ELECTRIC WINCH |
